Specifications
Warning models certified with SAE J595, SAE J845 Class 1, CA Title 13 and meet NFPA1901 and KKK1822 compliance when configured correctly.
Choose from 16 built-in flash patterns in solid, left-right split, top-bottom split, or criss-cross split flash mode.
Multi-units synchronization in simultaneous or alternating flash.
Reverse polarity protection.
Weatherproof and vibration resistant design for internal or external use.
Solid aluminium base for efficient heat dissipation.
Product Specifications
Product code 02200064 Product Name R6-E Warning Lighthead - RR Categories R6-E Responder, Modules, Responder Product Type Products Dimensions Length 170mm (6.7") Dimensions Height 108.7mm (4.29") Dimensions Width 30.5mm (1.2") Bezel Colour Black Colour Type Single Colour Storage Temperature -40°C - +75°C Maximum Current 2.1A@12VDC / 1.05A@24VDC Operating Temperature -30°C~+65°C Maximum Power 25.15W Synchronisation 15 Unit Sync LED Colour Red LEDs Fuse Rating 3A Lens Colour Red Lens Compliance ECE-R10, ECE-R65 (XR2), SAE J595 Class 1, SAE J845 Class 1 Input Voltage 12VDC~24VDC Mounting Option Surface Mount Cable Type Cable (Pigtail) LED Quantity 12x LEDs IP Rating IPX7 Flash Patterns 16 Flash Patterns Wire Length 250mm Mounting Orientation Horizontal Gross Weight 0.35kg Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty -
