Specifications
Split colour capability with independent activation wires.
Multiple units are synchronizable, and can flash simultaneously or alternately.
Weatherproof and vibration resistant for external or internal use.
Non-volatile memory recalls last flash pattern used at power up.
Flange option for surface mount applications.
LEDs rated to 100,000 hours of operation.
19 built-in selectable flash patterns.
Reverse polarity protection.Product Specifications
Product code 02060194 Product Name S-PAL06 Warning Lightheads x2 (Split Colour) - RR Categories Lighting, Modules, Covert Hideaways, S-PAL06 Product Type Products Dimensions Length 28mm Dimensions Height 28mm Dimensions Width 30mm Bezel Colour Black Colour Type Split Colour Maximum Current 1.3A@12VDC Maximum Power 15.6W Connection 3 Pin Connector LED Colour Red LEDs Fuse Rating 2A Lens Colour Clear Lens Compliance ECE R10 Nominal Voltage 12VDC Mounting Option Hideaway Cable Type Cable (Straight) LED Quantity 6LED Lighthead Quantity 2x Lightheads IP Rating IP67 Flash Patterns 19 Flash Patterns Warranty 5 Year Warranty -
